Package Contains 4 Shocks
You'll be getting two front and two rear shock absorbers.
Select Front Lift
Select Rear Lift
From $418.60
Original: $1,196.00
-65%Bilstein 5160 w/ Remote Reservoir Shocks Set for 2011-2022 GMC Sierra 2500 HD 4WD RWD w/4-6" lift—
$1,196.00
$418.60The Story
Part Numbers & Details
Bilstein 2 Year Warranty
Manufacturer Warranty protects against defects and premature failure.Choose Your Desired Lift Height Above
Make a selection from the drop-down menu above to get the correct length shock absorber for your vehicle.Fits 4WD & RWD vehicles
This product works for 4WD and RWD vehicles.Reservoir Mounts Included
All necessary washers, bushings, and nuts included. Factory shock mounting bolts are reused for installation. An optional billet aluminum reservoir clamp is available for a more clean and compact look.Rugged Reservoir Design
Added external reservoir provides increased control and durability over the harshest terrainDigressive Valving System
Digressive valving provides increased control over unwanted body motions with increased bump complianceSpecifications
| Part Number Options | Lift/Lowered | Position | Item | Quantity | Extended Length | Compressed Length | Travel | Top Mount | Bottom Mount | Reservoir | Color | Finish | Boot Included | Internal Design |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 25-311884 | 0-1.5" Lift | Front | Shock Absorber | 2 | ||||||||||
| 25-311891 | 0-2" Lift | Rear | Shock Absorber | 2 | ||||||||||
| 25-218206 | 3-5" Lift | Rear | Shock Absorber | 2 | 31.26" | 18.17" | 13.09" | EYELET | EYELET | Yes | Silver | Zinc Plated | No | Monotube |
| 25-218190 | 4-6" Lift | Front | Shock Absorber | 2 | 24.23" | 15.57" | 8.66" | BARPIN | CLEVIS | Yes | Silver | Zinc Plated | No | Monotube |
Product Details
With an added remote reservoir, the Bilstein B8 5160 provides ultimate vehicle control on even the harshest terrain. Zinc plating and increased oil capacity dissipate more heat assuring long term durability. Reservoir mounts are included in the box. An optional billet aluminum reservoir clamp is available for a more clean and compact look.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Part Numbers & Details
Package Contains 4 Shocks
You'll be getting two front and two rear shock absorbers.Bilstein 2 Year Warranty
Manufacturer Warranty protects against defects and premature failure.Choose Your Desired Lift Height Above
Make a selection from the drop-down menu above to get the correct length shock absorber for your vehicle.Fits 4WD & RWD vehicles
This product works for 4WD and RWD vehicles.Reservoir Mounts Included
All necessary washers, bushings, and nuts included. Factory shock mounting bolts are reused for installation. An optional billet aluminum reservoir clamp is available for a more clean and compact look.Rugged Reservoir Design
Added external reservoir provides increased control and durability over the harshest terrainDigressive Valving System
Digressive valving provides increased control over unwanted body motions with increased bump complianceSpecifications
| Part Number Options | Lift/Lowered | Position | Item | Quantity | Extended Length | Compressed Length | Travel | Top Mount | Bottom Mount | Reservoir | Color | Finish | Boot Included | Internal Design |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 25-311884 | 0-1.5" Lift | Front | Shock Absorber | 2 | ||||||||||
| 25-311891 | 0-2" Lift | Rear | Shock Absorber | 2 | ||||||||||
| 25-218206 | 3-5" Lift | Rear | Shock Absorber | 2 | 31.26" | 18.17" | 13.09" | EYELET | EYELET | Yes | Silver | Zinc Plated | No | Monotube |
| 25-218190 | 4-6" Lift | Front | Shock Absorber | 2 | 24.23" | 15.57" | 8.66" | BARPIN | CLEVIS | Yes | Silver | Zinc Plated | No | Monotube |
Product Details
With an added remote reservoir, the Bilstein B8 5160 provides ultimate vehicle control on even the harshest terrain. Zinc plating and increased oil capacity dissipate more heat assuring long term durability. Reservoir mounts are included in the box. An optional billet aluminum reservoir clamp is available for a more clean and compact look.
