Old Man Emu Rear Leaf Spring Kit for 2011-2017 Ford F350 Super Duty 4WD w/3" lift
HomeStore

Old Man Emu Rear Leaf Spring Kit for 2011-2017 Ford F350 Super Duty 4WD w/3" lift

Old Man Emu Rear Leaf Spring Kit for 2011-2017 Ford F350 Super Duty 4WD w/3" lift

Select Rear Load Rating
From $1,521.60
Old Man Emu Rear Leaf Spring Kit for 2011-2017 Ford F350 Super Duty 4WD w/3" lift—
$1,521.60

The Story

Part Numbers & Details
Pair of Rear Leaf Springs
Package contains two leaf springs. Bushings included when required. If no bushing supplied re-use OE bushings.
Old Man Emu 3 Year / 35,000 Mile Warranty
Manufacturer warranty protects against defects and premature failure.
Choose Options Above
Select options from the drop-down menu(s) above to customize your kit.
Important Fitment Note
When bull bar and/or winch are fitted use FK74 on both coils to restore nominal lift height.
Designed for 4WD vehicles
This product only works for 4WD vehicles.
Important Fitment Note
Fitment of a FK81 Caster Correction Kit will provide approximately 3.5 to 4.0 degrees of extra caster
Necessary Hardware Included
Shackles, Ubolts, and other components included if needed for your application.
Designed for Optimum Comford
Two-stage leaf pack featured on most rear springs. When unladen, the vehicle is largely riding on the primary stage, with the secondary stage providing additional support when a heavy load is added
Tested and True
Load testing ensures the spring meets the required specification
Increased ride comfort and longevity
Draw-tapered and diamond-cut leaves ensure the load is progressively distributed over a larger surface area, reducing the high stresses that develop at leaf ends
Military wrap
Designed to provide added safety
Specifications
Part Number Options Item Quantity Rear Load Rating
EL40XL Leaf Spring Extra Leaf 2 Constant 450 kg
EL077R Rear Leaf Spring 2 Constant 450 kg
EL077R Rear Leaf Spring 2 Medium Load
OMESB109 Spring Bush 2 Constant 450 kg
OMESB109 Spring Bush 2 Medium Load
OMEU78 U-Bolt Kit 4 Constant 450 kg
OMEU77 U-Bolt Kit 4 Medium Load
Product Details

As a critical component of integrated 4×4 suspension systems, Emu Dakar leaf springs are engineered to provide optimum ride quality and performance regardless of the operating conditions the vehicle’s suspension is required to work under. With numerous spring options available to suit a multitude of applications, you can set your vehicle up for a multitude of purposes from Overlanding to hauling the essentials to the job site. For the most harmonious package, improved ride, handling, and load-carrying capacity make sure to match a set of Emu Dakar leaf springs to a set of Old Man Emu 4×4 shock absorbers

Old Man Emu Rear Leaf Spring Kit for 2011-2017 Ford F350 Super Duty 4WD w/3" lift - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

Part Numbers & Details
Pair of Rear Leaf Springs
Package contains two leaf springs. Bushings included when required. If no bushing supplied re-use OE bushings.
Old Man Emu 3 Year / 35,000 Mile Warranty
Manufacturer warranty protects against defects and premature failure.
Choose Options Above
Select options from the drop-down menu(s) above to customize your kit.
Important Fitment Note
When bull bar and/or winch are fitted use FK74 on both coils to restore nominal lift height.
Designed for 4WD vehicles
This product only works for 4WD vehicles.
Important Fitment Note
Fitment of a FK81 Caster Correction Kit will provide approximately 3.5 to 4.0 degrees of extra caster
Necessary Hardware Included
Shackles, Ubolts, and other components included if needed for your application.
Designed for Optimum Comford
Two-stage leaf pack featured on most rear springs. When unladen, the vehicle is largely riding on the primary stage, with the secondary stage providing additional support when a heavy load is added
Tested and True
Load testing ensures the spring meets the required specification
Increased ride comfort and longevity
Draw-tapered and diamond-cut leaves ensure the load is progressively distributed over a larger surface area, reducing the high stresses that develop at leaf ends
Military wrap
Designed to provide added safety
Specifications
Part Number Options Item Quantity Rear Load Rating
EL40XL Leaf Spring Extra Leaf 2 Constant 450 kg
EL077R Rear Leaf Spring 2 Constant 450 kg
EL077R Rear Leaf Spring 2 Medium Load
OMESB109 Spring Bush 2 Constant 450 kg
OMESB109 Spring Bush 2 Medium Load
OMEU78 U-Bolt Kit 4 Constant 450 kg
OMEU77 U-Bolt Kit 4 Medium Load
Product Details

As a critical component of integrated 4×4 suspension systems, Emu Dakar leaf springs are engineered to provide optimum ride quality and performance regardless of the operating conditions the vehicle’s suspension is required to work under. With numerous spring options available to suit a multitude of applications, you can set your vehicle up for a multitude of purposes from Overlanding to hauling the essentials to the job site. For the most harmonious package, improved ride, handling, and load-carrying capacity make sure to match a set of Emu Dakar leaf springs to a set of Old Man Emu 4×4 shock absorbers
